3.4 Parameters 2-** Brakes
3.4.1 2-0* DC brakes
Parameter group for conguring the DC brake and DC hold
functions.
2-00 DC Hold/Preheat Current
Range: Function:
50
%*
[ 0 -
160 %]
NOTICE
Parameter 2-00 DC Hold/Preheat Current is
not eîš„ective when parameter 1-10 Motor
Construction = [1] PM, non-salient SPM.
NOTICE
The maximum value depends on the rated
motor current.
Avoid 100% current for too long. It may
damage the motor.
Enter a value for holding current as a percentage
of the rated motor current I
M,N
set in
parameter 1-24 Motor Current. 100% DC hold
current corresponds to I
M,N
.
This parameter holds the motor (holding torque)
or preheats the motor.
This parameter is active if [1] DC hold/Preheat is
selected in parameter 1-80 Function at Stop.
2-01 DC Brake Current
Range: Function:
50
%*
[ 0 -
1000 %
]
NOTICE
The maximum value depends on the rated
motor current. Avoid 100% current for too
long. It may damage the motor.
Enter a value for current as a percentage of the
rated motor current I
M,N
, see parameter 1-24 Motor
Current. 100% DC brake current corresponds to
I
M,N
.
DC brake current is applied on a stop command,
when the speed is lower than the limit set in:
•
Parameter 2-03 DC Brake Cut In Speed
[RPM].
•
Parameter 2-04 DC Brake Cut In Speed
[Hz], when the DC brake inverse function
is active, or via the serial communication
port.
The braking current is active during the time
period set in parameter 2-02 DC Braking Time.
2-02 DC Braking Time
Range: Function:
10 s* [0 - 60 s] Set the duration of the DC brake current set in
parameter 2-01 DC Brake Current, once
activated.
2-03 DC Brake Cut In Speed [RPM]
Range: Function:
Size
related*
[ 0 - 0
RPM]
NOTICE
Parameter 2-03 DC Brake Cut In Speed
[RPM] is not eîš„ective when
parameter 1-10 Motor Construction =
[1] PM, non-salient SPM.
Set the DC brake cut-in speed to activate
the DC brake current set in
parameter 2-01 DC Brake Current after a
stop command.
When parameter 1-10 Motor Construction is
set to [1] PM non-salient SPM, this value is
limited to 0 RPM (OFF).
2-04 DC Brake Cut In Speed [Hz]
Range: Function:
0.0 Hz* [0.0 - par.
4-14 Hz]
NOTICE
Parameter 2-04 DC Brake Cut In Speed
[Hz] is not eîš„ective when
parameter 1-10 Motor Construction =
[1] PM, non-salient SPM.
Set the DC brake cut-in speed for activation
of the DC brake current set in
parameter 2-01 DC Brake Current after a stop
command.
2-06 Parking Current
Range: Function:
50
%*
[ 0 -
1000 %]
NOTICE
Parameter 2-06 Parking Current and
parameter 2-07 Parking Time: Only active
if [1] PM, non-salient SPM is selected in
parameter 1-10 Motor Construction.
Set current as percentage of rated motor
current, parameter 1-24 Motor Current. Active
with parameter 1-73 Flying Start. The parking
current is active during the time period set in
parameter 2-07 Parking Time.
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 63
3 3
