Danfoss VLT AQUA Drive FC 202 Programming Guide

4.1.25 30-** Special Features
Param-
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
30-2* Adv. Start Adjust
30-22 Locked Rotor Detection ExpressionLimit All set-ups TRUE - Uint8
30-23 Locked Rotor Detection Time [s] ExpressionLimit All set-ups TRUE -2 Uint8
30-5* Unit Conguration
30-50 Heat Sink Fan Mode ExpressionLimit 2 set-ups TRUE - uint8
30-8* Compatibility (I)
30-81 Brake Resistor (ohm) ExpressionLimit All set-ups TRUE -2 Uint32
4.1.26 31-** Bypass Option
Param-
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
31-00 Bypass Mode [0] Drive All set-ups TRUE - Uint8
31-01 Bypass Start Time Delay 30 s All set-ups TRUE 0 Uint16
31-02 Bypass Trip Time Delay 0 s All set-ups TRUE 0 Uint16
31-03 Test Mode Activation [0] Disabled All set-ups TRUE - Uint8
31-10 Bypass Status Word 0 N/A All set-ups FALSE 0 V2
31-11 Bypass Running Hours 0 h All set-ups FALSE 74 Uint32
31-19 Remote Bypass Activation [0] Disabled 2 set-ups TRUE - Uint8
4.1.27 35-** Sensor Input Option
Param-
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
35-0* Temp. Input Mode
35-00 Term. X48/4 Temperature Unit [60] °C All set-ups TRUE - Uint8
35-01 Term. X48/4 Input Type [0] Not Connected All set-ups TRUE - Uint8
35-02 Term. X48/7 Temperature Unit [60] °C All set-ups TRUE - Uint8
35-03 Term. X48/7 Input Type [0] Not Connected All set-ups TRUE - Uint8
35-04 Term. X48/10 Temperature Unit [60] °C All set-ups TRUE - Uint8
35-05 Term. X48/10 Input Type [0] Not Connected All set-ups TRUE - Uint8
35-06 Temperature Sensor Alarm Function [5] Stop and trip All set-ups TRUE - Uint8
35-1* Temp. Input X48/4
35-14 Term. X48/4 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
35-15 Term. X48/4 Temp. Monitor [0] Disabled All set-ups TRUE - Uint8
35-16 Term. X48/4 Low Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-17 Term. X48/4 High Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-2* Temp. Input X48/7
35-24 Term. X48/7 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
35-25 Term. X48/7 Temp. Monitor [0] Disabled All set-ups TRUE - Uint8
35-26 Term. X48/7 Low Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-27 Term. X48/7 High Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-3* Temp. Input X48/10
35-34 Term. X48/10 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
35-35 Term. X48/10 Temp. Monitor [0] Disabled All set-ups TRUE - Uint8
35-36 Term. X48/10 Low Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-37 Term. X48/10 High Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-4* Analog Input X48/2
35-42 Term. X48/2 Low Current 4 mA All set-ups TRUE -5 Int16
Parameter Lists Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 281
