Danfoss VLT AQUA Drive FC 202 Programming Guide

4.1.5 3-** Reference/Ramps
Param-
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
3-0* Reference Limits
3-02 Minimum Reference ExpressionLimit All set-ups TRUE -3 Int32
3-03 Maximum Reference ExpressionLimit All set-ups TRUE -3 Int32
3-04 Reference Function [0] Sum All set-ups TRUE - Uint8
3-1* References
3-10 Preset Reference 0% All set-ups TRUE -2 Int16
3-11 Jog Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
3-13 Reference Site
[0] Linked to Hand/
Auto All set-ups TRUE - Uint8
3-14 Preset Relative Reference 0% All set-ups TRUE -2 Int32
3-15 Reference 1 Source [1] Analog Input 53 All set-ups TRUE - Uint8
3-16 Reference 2 Source [0] No function All set-ups TRUE - Uint8
3-17 Reference 3 Source [0] No function All set-ups TRUE - Uint8
3-19 Jog Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
3-4* Ramp 1
3-41 Ramp 1 Ramp Up Time ExpressionLimit All set-ups TRUE -2 Uint32
3-42 Ramp 1 Ramp Down Time ExpressionLimit All set-ups TRUE -2 Uint32
3-5* Ramp 2
3-51 Ramp 2 Ramp Up Time ExpressionLimit All set-ups TRUE -2 Uint32
3-52 Ramp 2 Ramp Down Time ExpressionLimit All set-ups TRUE -2 Uint32
3-8* Other Ramps
3-80 Jog Ramp Time ExpressionLimit All set-ups TRUE -2 Uint32
3-81 Quick Stop Ramp Time ExpressionLimit 2 set-ups TRUE -2 Uint32
3-84 Initial Ramp Time 0 s All set-ups TRUE -2 Uint16
3-85 Check Valve Ramp Time 0 s All set-ups TRUE -2 Uint16
3-86 Check Valve Ramp End Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
3-87 Check Valve Ramp End Speed [HZ] ExpressionLimit All set-ups TRUE -1 Uint16
3-88 Final Ramp Time 0 s All set-ups TRUE -2 Uint16
3-9* Digital Pot.Meter
3-90 Step Size 0.10% All set-ups TRUE -2 Uint16
3-91 Ramp Time 1 s All set-ups TRUE -2 Uint32
3-92 Power Restore [0] O All set-ups TRUE - Uint8
3-93 Maximum Limit 100% All set-ups TRUE 0 Int16
3-94 Minimum Limit 0% All set-ups TRUE 0 Int16
3-95 Ramp Delay ExpressionLimit All set-ups TRUE -3 TimD
Parameter Lists
VLT
®
AQUA Drive FC 202
254 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
44
