Danfoss VLT AQUA Drive FC 202 Programming Guide

4.1.15 16-** Data Readouts
Param-
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
16-0* General Status
16-00 Control Word 0 N/A All set-ups TRUE 0 V2
16-01 Reference [Unit]
0 ReferenceFeed-
backUnit All set-ups TRUE -3 Int32
16-02 Reference [%] 0% All set-ups TRUE -1 Int16
16-03 Status Word 0 N/A All set-ups TRUE 0 V2
16-05 Main Actual Value [%] 0% All set-ups TRUE -2 N2
16-09 Custom Readout
0 CustomRea-
doutUnit All set-ups TRUE -2 Int32
16-1* Motor Status
16-10 Power [kW] 0 kW All set-ups TRUE 1 Int32
16-11 Power [hp] 0 hp All set-ups TRUE -2 Int32
16-12 Motor Voltage 0 V All set-ups TRUE -1 Uint16
16-13 Frequency 0 Hz All set-ups TRUE -1 Uint16
16-14 Motor current 0 A All set-ups TRUE -2 Int32
16-15 Frequency [%] 0% All set-ups TRUE -2 N2
16-16 Torque [Nm] 0 Nm All set-ups TRUE -1 Int32
16-17 Speed [RPM] 0 RPM All set-ups TRUE 67 Int32
16-18 Motor Thermal 0% All set-ups TRUE 0 Uint8
16-20 Motor Angle 0 N/A All set-ups TRUE 0 Uint16
16-22 Torque [%] 0% All set-ups TRUE 0 Int16
16-23 Motor Shaft Power [kW] 0 kW All set-ups TRUE 1 Int32
16-24 Calibrated Stator Resistance 0.0000 Ohm All set-ups TRUE -4 Uint32
16-26 Power Filtered [kW] 0 kW All set-ups FALSE 0 Int32
16-27 Power Filtered [hp] 0 hp All set-ups FALSE -3 Int32
16-3* Drive Status
16-30 DC Link Voltage 0 V All set-ups TRUE 0 Uint16
16-31 System Temp. 0 °C All set-ups TRUE 100 Int8
16-32 Brake Energy /s 0 kW All set-ups TRUE 0 Uint32
16-33 Brake Energy Average 0 kW All set-ups TRUE 0 Uint32
16-34 Heatsink Temp. 0 °C All set-ups TRUE 100 Uint8
16-35 Inverter Thermal 0% All set-ups TRUE 0 Uint8
16-36 Inv. Nom. Current ExpressionLimit All set-ups TRUE -2 Uint32
16-37 Inv. Max. Current ExpressionLimit All set-ups TRUE -2 Uint32
16-38 SL Controller State 0 N/A All set-ups TRUE 0 Uint8
16-39 Control Card Temp. 0 °C All set-ups TRUE 100 Uint8
16-40 Logging Buer Full [0] No All set-ups TRUE - Uint8
16-49 Current Fault Source 0 N/A All set-ups TRUE 0 Uint8
16-5* Ref. & Feedb.
16-50 External Reference 0 N/A All set-ups TRUE -1 Int16
16-52 Feedback[Unit] 0 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-53 Digi Pot Reference 0 N/A All set-ups TRUE -2 Int16
16-54 Feedback 1 [Unit] 0 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-55 Feedback 2 [Unit] 0 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-56 Feedback 3 [Unit] 0 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-58 PID Output [%] 0% All set-ups TRUE -1 Int16
16-59 Adjusted Setpoint 0 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-6* Inputs & Outputs
16-60 Digital Input 0 N/A All set-ups TRUE 0 Uint16
16-61 Terminal 53 Switch Setting [0] Current All set-ups TRUE - Uint8
Parameter Lists Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 267
4 4
