Danfoss VLT AQUA Drive FC 202 Programming Guide

4.1.12 13-** Smart Logic
Param-
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
13-0* SLC Settings
13-00 SL Controller Mode ExpressionLimit 2 set-ups TRUE - Uint8
13-01 Start Event ExpressionLimit 2 set-ups TRUE - Uint8
13-02 Stop Event ExpressionLimit 2 set-ups TRUE - Uint8
13-03 Reset SLC
[0] Do not reset
SLC All set-ups TRUE - Uint8
13-1* Comparators
13-10 Comparator Operand ExpressionLimit 2 set-ups TRUE - Uint8
13-11 Comparator Operator ExpressionLimit 2 set-ups TRUE - Uint8
13-12 Comparator Value ExpressionLimit 2 set-ups TRUE -3 Int32
13-1* RS Flip Flops
13-15 RS-FF Operand S ExpressionLimit 2 set-ups TRUE - Uint8
13-16 RS-FF Operand R ExpressionLimit 2 set-ups TRUE - Uint8
13-2* Timers
13-20 SL Controller Timer ExpressionLimit 1 set-up TRUE -3 TimD
13-4* Logic Rules
13-40 Logic Rule Boolean 1 ExpressionLimit 2 set-ups TRUE - Uint8
13-41 Logic Rule Operator 1 ExpressionLimit 2 set-ups TRUE - Uint8
13-42 Logic Rule Boolean 2 ExpressionLimit 2 set-ups TRUE - Uint8
13-43 Logic Rule Operator 2 ExpressionLimit 2 set-ups TRUE - Uint8
13-44 Logic Rule Boolean 3 ExpressionLimit 2 set-ups TRUE - Uint8
13-5* States
13-51 SL Controller Event ExpressionLimit 2 set-ups TRUE - Uint8
13-52 SL Controller Action ExpressionLimit 2 set-ups TRUE - Uint8
13-9* User Dened Alerts
13-90 Alert Trigger [0] False 2 set-ups TRUE - Uint8
13-91 Alert Action [0] Info 2 set-ups TRUE - Uint8
13-92 Alert Text ExpressionLimit 2 set-ups TRUE 0 VisStr[20]
13-9* User Dened Readouts
13-97 Alert Alarm Word 0 N/A All set-ups FALSE 0 Uint32
13-98 Alert Warning Word 0 N/A All set-ups FALSE 0 Uint32
13-99 Alert Status Word 0 N/A All set-ups FALSE 0 Uint32
Parameter Lists Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 263
4 4
