Danfoss VLT AQUA Drive FC 202 Programming Guide

1-93 Thermistor Source
Option: Function:
(selected in parameter 3-15 Reference 1 Source,
parameter 3-16 Reference 2 Source, or
parameter 3-17 Reference 3 Source).
When using VLT
®
PTC Thermistor Card MCB
112, always select [0] None.
[0] * None
[1] Analog
Input 53
[2] Analog
Input 54
[3] Digital input
18
[4] Digital input
19
[5] Digital input
32
[6] Digital input
33
1-95 KTY Sensor Type
Option: Function:
Select the type of the thermistor sensor.
[0] * KTY Sensor 1
1 kΩ at 100 °C (212 °F).
[1] KTY Sensor 2
1 kΩ at 25 °C (77 °F).
[2] KTY Sensor 3
2 kΩ at 25 °C (77 °F).
1-96 KTY Thermistor Resource
Option: Function:
Select analog input terminal 54 as a thermistor
sensor input. Terminal 54 cannot be selected as
thermistor source if otherwise used as reference
(see parameter 3-15 Reference Resource 1 to
parameter 3-17 Reference Resource 3).
NOTICE
Connection of thermistor sensor
between terminals 54 and 55 (GND). See
chapter 3.3.15 PTC Thermistor Connection.
[0] * None
[2] Analog
input 54
1-97 KTY Threshold level
Range: Function:
80 °C* [-40 - 140 °C] Select the thermistor sensor threshold
level for motor thermal protection.
Parameter Description
VLT
®
AQUA Drive FC 202
62 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
