3-16 Reference 2 Source
Option: Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Select the reference input to be used for
the 2
nd
reference signal:
•
Parameter 3-15 Reference 1 Source.
•
Parameter 3-16 Reference 2 Source.
•
Parameter 3-17 Reference 3 Source.
Dene up to 3 dierent reference signals.
The sum of these reference signals denes
the actual reference.
[0] * No function
[1] Analog Input
53
[2] Analog Input
54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital
pot.meter
[21] Analog input
X30/11
[22] Analog input
X30/12
[23] Analog Input
X42/1
[24] Analog Input
X42/3
[25] Analog Input
X42/5
[29] Analog Input
X48/2
[30] Ext. Closed
Loop 1
[31] Ext. Closed
Loop 2
[32] Ext. Closed
Loop 3
[33] PCD Bus
Reference
[35] Digital input
select
The frequency converter selects AI53 or
AI54 as the reference source based on the
input signal dened in option [42] Ref
source bit 0 as 1 of the digital inputs. For
more information, see parameter group 5-1*
Digital Inputs, option [42] Ref source bit 0.
3-17 Reference 3 Source
Option: Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Select the reference input to be used for
the 3
rd
reference signal:
•
Parameter 3-15 Reference 1 Source.
•
Parameter 3-16 Reference 2 Source.
•
Parameter 3-17 Reference 3 Source.
Dene up to 3 dierent reference signals.
The sum of these reference signals denes
the actual reference.
[0] * No function
[1] Analog Input
53
[2] Analog Input
54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital
pot.meter
[21] Analog input
X30/11
[22] Analog input
X30/12
[23] Analog Input
X42/1
[24] Analog Input
X42/3
[25] Analog Input
X42/5
[29] Analog Input
X48/2
[30] Ext. Closed
Loop 1
[31] Ext. Closed
Loop 2
[32] Ext. Closed
Loop 3
[33] PCD Bus
Reference
[35] Digital input
select
The frequency converter selects AI53 or
AI54 as the reference source based on the
input signal dened in option [42] Ref
source bit 0 as 1 of the digital inputs. For
more information, see parameter group 5-1*
Digital Inputs, option [42] Ref source bit 0.
