Danfoss VLT AQUA Drive FC 202 Programming Guide

The relation depends on the type of unit selected in
parameter 0-30 Custom Readout Unit:
Unit type Speed relation
Dimensionless
Linear
Speed
Flow, volume
Flow, mass
Velocity
Length
Temperature
Pressure Quadratic
Power Cubic
Table 3.3 Speed Relations for Dierent Unit Types
0-30 Custom Readout Unit
Option: Function:
Program a value to be shown in the LCP display.
The value has a linear, squared, or cubed relation
to speed. This relation depends on the unit
selected (see Table 3.3). The actual calculated
value can be read in parameter 16-09 Custom
Readout, and/or shown in the display by selecting
[1609] Custom Readout in parameter 0-20 Display
Line 1.1 Small to parameter 0-24 Display Line 3
Large.
[0]
[1] * %
[5] PPM
[10] 1/min
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
0-30 Custom Readout Unit
Option: Function:
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
0-31 Custom Readout Min Value
Range: Function:
Size
related*
[ -999999.99 -
100.00
CustomRea-
doutUnit]
This parameter allows selection of
the minimum value of the custom-
dened readout (occurs at zero
speed). It is only possible to select a
value dierent from 0 when selecting
a linear unit in
parameter 0-30 Custom Readout Unit.
For quadratic and cubic units, the
minimum value is 0.
0-32 Custom Readout Max Value
Range: Function:
100 Custom-
ReadoutUnit*
[ par. 0-31 -
999999.99
CustomRea-
doutUnit]
This parameter sets the
maximum value to be shown
when the speed of the motor
has reached the set value for
parameter 4-13 Motor Speed High
Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed
Unit).
Parameter Description
VLT
®
AQUA Drive FC 202
34 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
