Danfoss VLT AQUA Drive FC 202 Programming Guide

3.8.6 6-5* Analog Output 1
Parameters for conguring the scaling and limits for analog
output 1, that is terminal 42. Analog outputs are current
outputs: 0/4–20 mA. Common terminal (terminal 39) is the
same terminal and has the same electrical potential for
analog common and digital common connection.
Resolution on analog output is 12 bit.
6-50 Terminal 42 Output
Option: Function:
NOTICE
Values for setting the minimum
reference are found in
parameter 3-02 Minimum Reference and
values for maximum reference in
parameter 3-03 Maximum Reference.
Select the function of terminal 42 as an
analog current output. A motor current of
20 mA corresponds to I
max
.
[0] No
operation
[52] MCO
0-20mA/
0-10V
[53] MCO
4-20mA
[100]
*
Output
freq. 0-100
0–100 Hz (0–20 mA).
[101] Reference
Min-Max
Minimum reference - maximum reference (0–
20 mA).
[102] Feedback
+-200%
-200% to +200% of parameter 3-03 Maximum
Reference (0–20 mA).
[103] Motor cur.
0-Imax
0–Inverter maximum current
(parameter 16-37 Inv. Max. Current), (0–20 mA)
[104] Torque 0-
Tlim
0–Torque limit (parameter 4-16 Torque Limit
Motor Mode), (0–20 mA).
[105] Torque 0-
Tnom
0–Motor rated torque (0–20 mA).
[106] Power 0-
Pnom
0–Motor rated power (0–20 mA).
[107] Speed 0-
HighLim
0–Speed high limit (parameter 4-13 Motor
Speed High Limit [RPM] and
parameter 4-14 Motor Speed High Limit [Hz]),
(0–20 mA)
[108] Torque
+-160%
(0–20 mA).
[109] Out frq 0-
Fmax
[113] Ext. Closed
Loop 1
0–100% (0–20 mA).
[114] Ext. Closed
Loop 2
0–100% (0–20 mA).
6-50 Terminal 42 Output
Option: Function:
[115] Ext. Closed
Loop 3
0–100% (0–20 mA).
[116] Cascade
Reference
[117] Shaft
Power
[118] Shaft
Power
4-20mA
[130] Out frq
0-100
4-20mA
0–100 Hz.
[131] Reference
4-20mA
Minimum reference–maximum reference.
[132] Feedback
4-20mA
-200% to +200% of parameter 3-03 Maximum
Reference.
[133] Motor cur.
4-20mA
0–Inverter maximum current
(parameter 16-37 Inv. Max. Current).
[134] Torq.0-lim
4-20 mA
0–Torque limit (parameter 4-16 Torque Limit
Motor Mode).
[135] Torq.0-nom
4-20mA
0–Motor rated torque.
[136] Power
4-20mA
0–Motor rated power.
[137] Speed
4-20mA
0–Speed high limit (parameter 4-13 Motor
Speed High Limit [RPM] and
parameter 4-14 Motor Speed High Limit [Hz]).
[138] Torque
4-20mA
[139] Bus ctrl. 0–100% (0–20 mA)
[140] Bus ctrl.
4-20 mA
0–100%.
[141] Bus ctrl t.o. 0–100% (0–20 mA).
[142] Bus ctrl t.o.
4-20mA
0–100%.
[143] Ext. CL 1
4-20mA
0–100%.
[144] Ext. CL 2
4-20mA
0–100%.
[145] Ext. CL 3
4-20mA
0–100%.
[146] Cascade
Ref.
4-20mA
[147] Main act
val 0-20mA
[148] Main act
val 4-20mA
[150] Out frq 0-
Fmax
4-20mA
[156] Flow Rate
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 95
3 3
