Closed-loop Set-up Wizard
Parameter Range Default Function
0-03 Regional Settings [0] International
[1] US
0
0-06 GridType [0] -[[132] see start-up wizard
for open-loop application
Size selected Select operating mode for restart upon
reconnection of the adjustable frequency
drive to AC line voltage after power-down.
1-00 Configuration Mode [0] Open-loop
[3] Closed-loop
0 Change this parameter to Closed-loop.
1-10 Motor Construction *[0] Motor construction
[1] PM, non-salient SPM
[0] Asynchron Setting the parameter value might change
these parameters:
1-01 Motor Control Principle
1-03 Torque Characteristics
1-14 Damping Gain
1-15 Low Speed Filter Time Const
1-16 High Speed Filter Time Const
1-17 Voltage filter time const
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-30 Stator Resistance (Rs)
1-33 Stator Leakage Reactance (X1)
1-35 Main Reactance (Xh)
1-37 d-axis Inductance (Ld)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-66 Min. Current at Low Speed
1-72 Start Function
1-73 Flying Start
4-19 Max Output Frequency
4-58 Missing Motor Phase Function
1-20 Motor Power
0.09–110 kW Size related Enter motor power from nameplate data.
1-22 Motor Voltage 50.0–1000.0 V Size related Enter motor voltage from nameplate data.
1-23 Motor Frequency 20.0–400.0 Hz Size related Enter motor frequency from nameplate data.
1-24 Motor Current 0.0–10000.00 A Size related Enter motor current from nameplate data.
1-25 Motor Nominal Speed 100.0–9999.0 RPM Size related Enter motor nominal speed from nameplate
data.
1-26 Motor Cont. Rated Torque 0.1–1000.0 Size related This parameter is available only when
1-10 Motor Construction Design is set to [1]
PM, non-salient SPM.
NOTICE!
Changing this parameter affects the
settings of other parameters.
1-29 Automatic Motor Adaption
(AMA)
Off Performing an AMA optimizes motor
performance.
1-30 Stator Resistance (Rs) 0.000–99.990 Size related Set the stator resistance value.
Product Overview Design Guide
32 Danfoss A/S © Rev. 2014-01-14 All rights reserved. MG18C522
