Danfoss VLT HVAC Basic Drive FC 101 Design Guide

4.2.2 Harmonic Filters
3x380–480 V 50 Hz
Power [kW] Drive input current
Continuous [A]
Default switching
frequency [kHz]
THID level [%] Order number filter IP00 Code number filter IP20
22 41.5 4 4 130B1397 130B1239
30 57 4 3 130B1398 130B1240
37 70 4 3 130B1442 130B1247
45 84 3 3 130B1442 130B1247
55 103 3 5 130B1444 130B1249
75 140 3 4 130B1445 130B1250
90 176 3 4 130B1445 130B1250
Table 4.3 AHF Filters (5% current distortion)
3x380–480 V 50 Hz
Power [kW] Drive input current
Continuous [A]
Default switching
frequency [kHz]
THID level [%] Order number filter IP00 Code number filter IP20
22 41.5 4 6 130B1274 130B1111
30 57 4 6 130B1275 130B1176
37 70 4 9 130B1291 130B1201
45 84 3 9 130B1291 130B1201
55 103 3 9 130B1292 130B1204
75 140 3 8 130B1294 130B1213
90 176 3 8 130B1294 130B1213
Table 4.4 AHF Filters (10% current distortion)
3x440–480 V 60 Hz
Power [kW] Drive input current
Continuous [A]
Default switching
frequency [kHz]
THID level [%] Order number filter IP00 Code number filter IP20
22 34.6 4 3 130B1792 130B1757
30 49 4 3 130B1793 130B1758
37 61 4 3 130B1794 130B1759
45 73 3 4 130B1795 130B1760
55 89 3 4 130B1796 130B1761
75 121 3 5 130B1797 130B1762
90 143 3 5 130B1798 130B1763
Table 4.5 AHF Filters (5% current distortion)
3x440–480 V 60 Hz
Power [kW] Drive input current
Continuous [A]
Default switching
frequency [kHz]
THID level [%] Order number filter IP00 Code number filter IP20
22 34.6 4 6 130B1775 130B1487
30 49 4 8 130B1776 130B1488
37 61 4 7 130B1777 130B1491
45 73 3 9 130B1778 130B1492
55 89 3 8 130B1779 130B1493
75 121 3 9 130B1780 130B1494
90 143 3 10 130B1781 130B1495
Table 4.6 AHF Filters (10% current distortion)
