Danfoss VLT HVAC Basic Drive FC 101 Design Guide

130BB764.10
1
2
3
4
98
97
96
99
95
93
92
91
L1
L1
L1
U
V
w
Figure 5.5 H8 Frame
IP20 380-480 V 125 hp [90 kW]
IP20 200–240 V 50–60 hp [37–45 kW]
IP20 525–600 V 100–125 hp [75–90 kW]
1 Line
2 Relays
3 Ground
4 Motor
Table 5.10 Legend to
MOTOR
MOTOR
U V W
99
130BT302.12
Figure 5.6 H9 Frame
IP20 600 V 3–10 hp [2.2–7.5 kW]
How to Install Design Guide
62 Danfoss A/S © Rev. 2014-01-14 All rights reserved. MG18C522
