Danfoss VLT HVAC Basic Drive FC 101 Design Guide

1
95
99
L1 91 / L2 92 / L3 93
U 96 / V 97 / W 98
03 02 01
06 05 04
2
3
4
130BB762.10
Figure 5.3 H6 Frame
IP20 380–480 V 40–60 hp [30–45 kW]
IP20 200–240 V 20–25 hp [15–18.5 kW]
IP20 525–600 V 30–40 hp [22–30 kW]
1 Line
2 Motor
3 Ground
4 Relays
Table 5.8 Legend to Figure 5.3
1
2
3
4
130BB763.10
Figure 5.4 H7 Frame
IP20 380–480 V 75–100 hp [55–75 kW]
IP20 200–240 V 30–40 hp [22–30 kW]
IP20 525–600 V 60–75 hp [45–55 kW]
1
Line
2 Relays
3 Ground
4 Motor
Table 5.9 Legend to Figure 5.4
How to Install Design Guide
MG18C522 Danfoss A/S © Rev. 2014-01-14 All rights reserved. 61
5 5
