Danfoss VLT HVAC Basic Drive FC 101 Design Guide

Circuit Breaker Fuse
UL Non-UL UL Non-UL
Bussmann Bussmann Bussmann Bussmann Max fuse
Power [kW] Type RK5 Type RK1 Type J Type T Type G
3x380–480 V IP20
0.37 FRS-R-10 KTS-R10 JKS-10 JJS-10 10
0.75 FRS-R-10 KTS-R10 JKS-10 JJS-10 10
1.5 FRS-R-10 KTS-R10 JKS-10 JJS-10 10
2.2 FRS-R-15 KTS-R15 JKS-15 JJS-15 16
3 FRS-R-15 KTS-R15 JKS-15 JJS-15 16
4 FRS-R-15 KTS-R15 JKS-15 JJS-15 16
5.5 FRS-R-25 KTS-R25 JKS-25 JJS-25 25
7.5 FRS-R-25 KTS-R25 JKS-25 JJS-25 25
11 FRS-R-50 KTS-R50 JKS-50 JJS-50 50
15 FRS-R-50 KTS-R50 JKS-50 JJS-50 50
18.5 FRS-R-80 KTS-R80 JKS-80 JJS-80 65
22 FRS-R-80 KTS-R80 JKS-80 JJS-80 65
30
Cutler-Hammer
EGE3125FFG
Moeller NZMB1-
A125
FRS-R-125 KTS-R125 JKS-R125 JJS-R125 80
37 FRS-R-125 KTS-R125 JKS-R125 JJS-R125 100
45 FRS-R-125 KTS-R125 JKS-R125 JJS-R125 125
55
Cutler-Hammer
JGE3200FFG
Moeller NZMB1-
A200
FRS-R-200 KTS-R200 JKS-R200 JJS-R200 150
75 FRS-R-200 KTS-R200 JKS-R200 JJS-R200 200
90
Cutler-Hammer
JGE3250FFG
Moeller NZMB2-
A250
FRS-R-250 KTS-R250 JKS-R250 JJS-R250 250
3x525–600 V IP20
2.2 FRS-R-20 KTS-R20 JKS-20 JJS-20 20
3 FRS-R-20 KTS-R20 JKS-20 JJS-20 20
5 [3.7] FRS-R-20 KTS-R20 JKS-20 JJS-20 20
5.5 FRS-R-20 KTS-R20 JKS-20 JJS-20 20
7.5 FRS-R-20 KTS-R20 JKS-20 JJS-20 30
11 FRS-R-30 KTS-R30 JKS-30 JJS-30 35
15 FRS-R-30 KTS-R30 JKS-30 JJS-30 35
18.5
Cutler-Hammer
EGE3080FFG
Cutler-Hammer
EGE3080FFG
FRS-R-80 KTN-R80 JKS-80 JJS-80 80
22 FRS-R-80 KTN-R80 JKS-80 JJS-80 80
30 FRS-R-80 KTN-R80 JKS-80 JJS-80 80
37
Cutler-Hammer
JGE3125FFG
Cutler-Hammer
JGE3125FFG
FRS-R-125 KTN-R125 JKS-125 JJS-125 125
45 FRS-R-125 KTN-R125 JKS-125 JJS-125 125
55 FRS-R-125 KTN-R125 JKS-125 JJS-125 125
75
Cutler-Hammer
JGE3200FAG
Cutler-Hammer
JGE3200FAG
FRS-R-200 KTN-R200 JKS-200 JJS-200 200
90 FRS-R-200 KTN-R200 JKS-200 JJS-200 200
3x380–480 V IP54
0.75 PKZM0-16 FRS-R-10 KTS-R-10 JKS-10 JJS-10 16
1.5 PKZM0-16 FRS-R-10 KTS-R-10 JKS-10 JJS-10 16
2.2 PKZM0-16 FRS-R-15 KTS-R-15 JKS-15 JJS-15 16
3 PKZM0-16 FRS-R-15 KTS-R-15 JKS-15 JJS-15 16
4 PKZM0-16 FRS-R-15 KTS-R-15 JKS-15 JJS-15 16
5.5 PKZM0-25 FRS-R-25 KTS-R-25 JKS-25 JJS-25 25
7.5 PKZM0-25 FRS-R-25 KTS-R-25 JKS-25 JJS-25 25
11 PKZM4-63 FRS-R-50 KTS-R-50 JKS-50 JJS-50 63
15 PKZM4-63 FRS-R-50 KTS-R-50 JKS-50 JJS-50
63
How to Install Design Guide
MG18C522 Danfoss A/S © Rev. 2014-01-14 All rights reserved. 69
