Circuit Breaker Fuse
UL Non-UL UL Non-UL
Bussmann Bussmann Bussmann Bussmann Max fuse
Power [kW] Type RK5 Type RK1 Type J Type T Type G
18.5 PKZM4-63 FRS-R-80 KTS-R-80 JKS-80 JJS-80 63
22
Moeller NZMB1-A125
FRS-R-80 KTS-R-80 JKS-80 JJS-80 125
30 FRS-R-125 KTS-R-125 JKS-125 JJS-125 125
37 FRS-R-125 KTS-R-125 JKS-125 JJS-125 125
45
Moeller NZMB2-A160
FRS-R-125 KTS-R-125 JKS-125 JJS-125 160
55 FRS-R-200 KTS-R-200 JKS-200 JJS-200 160
75
Moeller NZMB2-A250
FRS-R-200 KTS-R-200 JKS-200 JJS-200 200
90 FRS-R-250 KTS-R-250 JKS-200 JJS-200 200
Table 5.15 Circuit Breakers and Fuses
5.2.4
EMC-compatible Electrical Installation
General points to be observed to ensure EMC-compatible electrical installation.
•
Use only shielded/armored motor cables and shielded/armored control cables.
•
Connect the shield to ground at both ends.
•
Avoid installation with twisted shield ends (pigtails), since this ruins the shielding effect at high frequencies. Use
the cable clamps provided instead.
•
It is important to ensure good electrical contact from the installation plate through the installation screws to the
metal cabinet of the adjustable frequency drive.
•
Use starwashers and galvanically conductive installation plates.
•
Do not use shielded/armored motor cables in the installation cabinets.
How to Install Design Guide
70 Danfoss A/S © Rev. 2014-01-14 All rights reserved. MG18C522
