Parameter Range Default Function
1-20 Motor Power 0.12–110 kW/0.16–150 hp Size related Enter motor power from nameplate data.
1-22 Motor Voltage 50.0–1000.0 V Size related Enter motor voltage from nameplate data.
1-23 Motor Frequency 20.0–400.0 Hz Size related Enter motor frequency from nameplate data.
1-24 Motor Current 0.01–10000.00 A Size related Enter motor current from nameplate data.
1-25 Motor Nominal
Speed
100.0–9999.0 RPM Size related Enter motor nominal speed from nameplate data.
1-26 Motor Cont. Rated
Torque
0.1–1000.0 Size related
This parameter is available only when 1-10 Motor
Construction Design is set to [1] PM, non-salient
SPM.
NOTICE!
Changing this parameter affects the
settings of other parameters.
1-29 Automatic Motor
Adaption (AMA)
See 1-29 Automatic Motor
Adaption (AMA)
Off Performing an AMA optimizes motor performance.
1-30 Stator Resistance
(Rs)
0.000–99.990 Size related Set the stator resistance value.
1-37 d-axis Inductance
(Ld)
0–1000 Size related Enter the value of the d-axis inductance.
Obtain the value from the permanent magnet
motor data sheet. The de-axis inductance cannot
be found by performing an AMA.
1-39 Motor Poles 2–100 4 Enter the number of motor poles.
1-40 Back EMF at 1000
RPM
10–9000 Size related Line-Line RMS back EMF voltage at 1000 RPM.
1-73 Flying Start When PM is selected, Flying Start is enabled and
cannot disable.
1-73 Flying Start [0] Disabled
[1] Enabled
0
Select [1] Enable to enable the adjustable
frequency drive to catch a motor spinning due to
line drop-out. Select [0] Disable if this function is
not required. When is enabled 1-71 Start Delay and
1-72 Start Function have no function. is active in
VVC
plus
mode only.
3-02 Minimum Reference -4999–4999 0 The minimum reference is the lowest value
obtainable by summing all references.
3-03 Maximum Reference -4999–4999 50 The maximum reference is the lowest obtainable
by summing all references.
3-41 Ramp 1 Ramp Up
Time
0.05–3600.0 s Size related
Ramp-up time from 0 to rated 1-23 Motor
Frequency if Asynchron motor is selected; ramp-up
time from 0 to 1-25 Motor Nominal Speed if PM
motor is selected.
3-42 Ramp 1 Ramp
Down Time
0.05–3600.0 s Size related
Ramp-down time from rated 1-23 Motor Frequency
to 0 if Asynchron motor is selected; ramp-down
time from 1-25 Motor Nominal Speed to 0 if PM
motor is selected.
4-12 Motor Speed Low
Limit [Hz]
0.0–400 Hz 0 Hz Enter the minimum limit for low speed.
4-14 Motor Speed High
Limit [Hz]
0.0–400 Hz 65 Hz Enter the maximum limit for high speed.
4-19 Max Output
Frequency
0–400 Size related Enter the maximum output frequency value.
How to Program Design Guide
MG18C522 Danfoss A/S © Rev. 2014-01-14 All rights reserved. 77
6 6
