A-4 CLM Laminator
Clearance Requirements
The following measurements show the system dimensions when the input hopper, printer
access, and laminator access doors are open.
Single-Hopper System
We recommend that you provide a minimum of 3 inches (76.2 mm) of additional
clearance around the system to maintain access to the power cords and data cables,
to load and remove cards and supplies, and to provide ventilation.
34.8 in / 884 mm
(no impresser)
38.2 in / 970 mm
(with impresser)
8.2 in
207 mm
27.0 in
686 mm
3.6 in
92 mm
24.8 in
630 mm
9.0 in
229 mm
11.4 in
290 mm
14.3 in
363 mm
