98 Printer Manager
LaminateType
Use the LaminateType options to specify settings for the overlay materials used in the laminating
system.
The LaminateType setting displays in the Printer Setting menu only when a laminator
is attached to the printer.
Description
Default
Value Current Value (unit) Allowed Range
1) DatabaseVersion 1 14 [1 – 999]
2) ExclusiveOverlayInL1 Disabled
3) ExclusiveOverlayInL2 Disabled
4) OverlayDisplayed Name R1_mil_clear_DG_ms
5) OverlayLoadedInL1 Name R1_mil_Holo_DG_reg
6) OverlayLoadedInL2 Name R1_mil_clear_DG_ms
105) OverlayPartNumber 0 514910
106) OverlaySpeed 160 170 [100 – 250]
107)OverlaySpeed
AdjustmentL1
0 0 [-40 – 40]
108) OverlaySpeed
AdjustmentL2
0 0 [-40 – 40]
109) OverlayTemp 160 170 [100 – 200]
110) OverlayTemp
AdjustmentL1
0 0 [-20 – 40]
111) OverlayTemp
AdjustmentL2
0 0 [-20 – 40]
112) UserOverlay1Name None
113) UserOverlay2Name None
114) UserOver3Name None
115) UserOverlay4Name None
To Next Page
