CR805 Retransfer Card Printer Installation and Administrator’s Guide 17
Clean the Printhead Cam Rollers
Use the double-sided, adhesive-coated cleaning card to clean the printhead cam rollers. Perform
this procedure first.
1. Power off the printer, if necessary.
2. Unlock the access door lock, if necessary, and open the printer access door.
3. Remove the retransfer cartridge (C2) from the
printer, if necessary.
4. Peel off the wrapper from one side of the sticky cleaning card.
5. Insert the cleaning card vertically into the printer between the retransfer cartridge guidepost
and the rollers. Make sure that the adhesive side of the card is facing to the right and is
touching the rollers.
6. Move the cleaning card up and down along the rollers to remove any debris found on the
rollers.
7. Continue with “Clean the Inside of the Printer” on page 18.
The ink ribbon and retransfer cartridges
are shipped inside the printer.
Ink Ribbon
Cartridge
Guidepost
Sticky
Cleaning Card
Printhead
Cam Rollers
To Next Page
