DM16E1 / DM4E1 Operation and Installation Manual - 204-4001-19 23
# -------------------------------------------------------------------------
# DataCom Telematica – DM16E1 Multiplexer
#
# -------------------------------------------------------------------------
# Choose Equipment
#
# *1 - DM4E1 Multiplexer local
# *2 - DM4E1 Multiplexer 244391
#
#
#
#
#
#
#
#
#
#
#
# Option: [ ]
# -------------------------------------------------------------------------
# <ENTER> Refresh <ESC> Exit
# -------------------------------------------------------------------------
Option 1 always refers to local equipment (with which the Terminal port is connected). The remaining
options refer to remote equipment connected via the aggregate link.
Remote devices are listed in accordance with their serial numbers.
Some remote devices may not be available for management from this terminal. This is due, in general, to
the fact that there is local management available for this equipment, via a Terminal or via DmView.
Another possible reason is that the management link is not established yet. The equipment available for
management is marked with the indicator "*".
If the equipment on trial is chosen, then the password for ending the trial period is automatically lost. If the
user keys in <ENTER>, the equipment will continue to be used on trial.
Once an equipment is chosen (options 1 to 2 in the example), configuration can start, either locally or
remotely.
In order to update equipment management properties, use the "Refresh" option, activated by <ENTER>.
To return to the main screen of the Terminal, use the "Exit" option, activated by <ESC>. Following the
terminal standard, the main functions are detailed on the status bar (last line on the screen, between the
separators formed by "-").
Once the equipment to be configured has been chosen, the terminal will exhibit information on
configuration and status referring to these specific units. In the following sub-sections, details of the
configuration of the equipment interfaces will be addressed.
When
the trial period is over, the equipment is restarted and does not transmit data anymore. Equipment
with the trial time expired only restart working after the typing of the password.
