DM16E1 / DM4E1 Operation and Installation Manual - 204-4001-19 34
# -------------------------------------------------------------------------
# DataCom Telematica - DM16E1 Multiplexer
# /local/status
# -------------------------------------------------------------------------
# Choose Status view
#
# 0 - Equipment
# 1 - Slot AG1 - E3 SM Short Range Bidirectional 1310nm
# 2 - Slot AG2 - E3 Eletric
# 3 - E1 tributary Ports (16)
# 4 - V.35 Interface
# 5 - Empty Slot
# 6 - Router (2)
#
#
#
#
#
#
# Option: [ ]
# -------------------------------------------------------------------------
# <ENTER> Refresh <ESC> Exit
# -------------------------------------------------------------------------
3.12.1. Device Status
The equipment status menu is showed on the screen below.
# -------------------------------------------------------------------------
# DataCom Telematica - DM16E1 Multiplexer
# /local/status/equip
# -------------------------------------------------------------------------
# Equipment Status
#
# Up Time :[ 0d 01h 06m 23s ]
# Backup State :[ Failure ]
# Aggregate Link Error Ratio :[ FrameLoss ]
# Latched Alarms :[ High priority alarm ]
# Current Alarms :[ High priority alarm ]
# Alarm Output :[ ALARM ]
# Current Tests :[ No active tests ]
# Power Supply [Main] [Backup] :[ Ok ] [ Not Present ]
# 2048kHz E1 AIS Reference :[ Internal ]
# 2048kHz External Clock Status :[ Clock Error (ignored) ]
# External Alarm 1 :[ Disabled ]
# External Alarm 2 :[ Disabled ]
# External Alarm 3 :[ Disabled ]
# -------------------------------------------------------------------------
# Reset latched [A]larms Ac[K] Alarm Semi-Automatic [B]ackup return
# <ENTER> Refresh <ESC> Exit
# -------------------------------------------------------------------------
Possible status options:
Up Time: Indicates how long the device has been on since last resetting.
BackUp State: Indicates how the link protection for the main aggregate (MAIN) is acting. If the
protection is off, this field will always indicate the use of the main channel (Using Main).
Common values for all topologies:
o Using Main: The data are passing through the main aggregate link (MAIN).
o Failure: Fail in main and backup link.
Specific value for Point to Point topologies (Point to Point):
o Using Backup: The device is using the data provided from the protection link (BACKUP).
The aggregates are operating in redundant transmission.
Values for Ring topologies:
o Using Ring Backup: Indicates that, due to a failure in the main link, the device is using
data provided by the protection ring (BACKUP ring).
