OPERATING MODE
PRODUCT REFERENCE GUIDE
101
Conveyor Width
Conveyor Width
Enter the conveyor width. The Conveyor Width is the area on the conveyor that a bar code can
be read by the camera.
Trigger Source
Trigger Source
Select Position Sensor, Photo Sensor, or Trigger Message from the drop-down list.
•
Position Sensor: triggers when selected position sensor senses a package.
•
Photo Sensor: triggers when a photoelectric sensor is blocked. This can also be a contact
closure or a 24VDC signal from a PLC.
•
Trigger Message: triggers when a trigger message is received from an external device.
•
Ethernet / IP: when a trigger message comes from PLC on Ethernet IP Connection
If you select Photo Sensor or Trigger Message as your Trigger Source, the following Trigger
Source options are available.
Trigger Controller
If Trigger Message is the Trigger Source, select which camera in your system is controlling the
trigger message.
Position Sensor Settings (Primary Controller)
Position Sensor Type
Select No Position Sensor, Light Curtain, Dimensioner, S85, or S85 with Light Curtain from the
drop-down list, depending on the specific position sensor used by the system.
Position Sensor Height Offset
Enter the distance between the light curtain’s (light array’s) zero height reference point and the
conveyor’s surface. This should be set to zero (0) for other, non-light curtain position sensors.
Position Sensor Transmit Delay
Enter the distance from the position sensor to the transmit point in the field provided.
DL Light Curtain Settings
Connected to
Select a camera in the system to which the light curtain is connected.
Multicast LC Focus Data
Select Disable or Enable from drop-down. Enable if you have a Light Curtain and there are
multiple camera’s that should use the Light Curtain signal for focusing.
Dimensioner Settings
Place Dimensioning Results Based on Tach
Select the check-box to enable placement of the Dimensioning results based on the
tachometer. This option works in conjunction with the DM3610 when the Datalogic Message is
selected as it's transmit message format. The camera will receive the message at the defined
Transmit Point Distance parameter.
Transmit Point Distance
Enter the distance in the field provided.This is the distance at which the camera is looking for
the information from the DM3610/DC3000Transmit Point Reference Edge. This option is in
reference to the DM3610 message to the camera.
This option is different than the "Distance To Transmit Point" which is the point where the
camera transmits the host message
Transmit Point Reference Edge
Select Leading Edge or Trailing Edge from the drop-down list to reference the leading or trailing
edge of the package.This option is in reference to the DM3610 message to the camera.
It is different than the "Transmit Point Reference Edge which is the which is the package edge
for the camera transmits the host.
Side by Side Verification
Select Enabled or Disabled from the drop-down list if your system requires Side by Side
Verification. This is only available for Dimensioners.
S85 Configuration
Number of S85’s
