Datalogic Matrix 300

MATRIX 300™ REFERENCE MANUAL
96
6
Code 128 0.38 mm (15 mils)
CONDITIONS:
Hardware Settings
Code Symbology
Code 128
Code Resolution
0.38 mm (15 mils)
Tilt Angle
45°
Skew Angle
15°
Software Parameters
Reading Distance (mm)
180
452
452
412-xxx RED Wide
A
B
Exposure Time (µs)
140
320
3300
Gain
25
25
15
Illuminator Lighting Mode
Very High Power Strobed
High Power Strobed
Reading Distance
Horizontal Reading Width
mm
in
0 2 4 6 8 10 12 14 16 18 20
0
2
4
10
-2
-4
-10
6
8
-6
-8
