6.1.2 Matrix 300 4x2 9 mm Liquid Lens Global FOV Diagrams
The following diagrams show the maximum obtainable Field of View for 1D and 2D codes
using Processing Mode = Advanced Code Setting. Depending on the code resolution,
symbology, and number of characters in the code, the Reading Area can be different
from the FOV. See the reference Reading Diagrams in par. 6.4 for reading area examples.
Horizontal FOV
in
0 1 2 3 4 5 6 7 8 9 10 11 12 13
0
1
2
5
-1
-2
-5
3
4
-3
-4
mm
5 mils
7.5 mils
15 mils
10 mils
2D Code FOV
Distance
Horizontal FOV
in
0 2 4 6 8 10 12 14 16 18 20 22
0
2
4
10
-2
-4
-10
6
8
-6
-8
mm
10 mils
12 mils
13 mils
15 mils
1D Code FOV
Distance
