MATRIX 300™ REFERENCE MANUAL
142
A
USER INTERFACE - SERIAL HOST
RS232 PC-side connections
1
5
9
6
9-pin male connector
13
25
14
1
25-pin male connector
Pin
Name
Pin
Name
2
RX
3
RX
3
TX
2
TX
5
GND
7
GND
7
RTS
4
RTS
8
CTS
5
CTS
How To Build A Simple Interface Test Cable:
The following wiring diagram shows a simple test cable including power, external (push-
button) trigger and PC RS232 COM port connections.
Figure 98- Test Cable for Matrix 300™
M12 17-pin female
11
RX
TX
17
Matrix 300™
1
2
Vdc
GND
9-pin D-sub female
GND
TX
RX
PC
2
3
5
Power Supply
Power GND
VS (10 – 30 VDC)
Trigger
I1B
5
I1A
6
