7 SOFTWARE CONFIGURATION
Software configuration of your Matrix 300™ for static reading or simple code reading
applications can be accomplished by the Rapid Configuration procedure using the
X-PRESS™ HMI (which requires no external configuration program) or by using the
VisiSet™ Setup Wizard for easy setup. These procedures are described in chapter 1.
For other applications use VisiSet™, connecting to the reader through one of the serial ports.
NOTE: For Ethernet applications, connections to VisiSet™ can be made
directly through the Ethernet port of the reader, or QL500 or BM2x0 Host
Interface module. See the "Configuration Through Ethernet" page in the
VisiSet™ Help On-Line, or the "Matrix Family Setup Procedure Using
Programming Barcodes" document on the Mini-DVD.
7.1 VISISET™ SYSTEM REQUIREMENTS
To install and run VisiSet™ you should have a Laptop or PC that meets or exceeds the
following:
Pentium processor
Windows: 98/2000, NT 4.0, XP, Vista, 7 or 8
32 MB Ram
5 MB free HD space
one free RS232 serial port with 115 Kbaud (or USB-Serial adapter)
one Ethernet TCP/IP port
Video Adapter (1024 x 768) or better using more than 256 colors
7.2 INSTALLING VISISET™
To install VisiSet™, proceed as follows:
1. Turn on the Laptop or PC that will be used for configuration (connected to the Matrix
300™ communication ports).
2. After Windows finishes booting, insert the Mini-DVD provided.
3. Launch VisiSet™ installation by clicking Install.
4. Follow the instructions in the installation procedure.
