MATRIX 300™ REFERENCE MANUAL
134
10
10 TECHNICAL FEATURES
ELECTRICAL FEATURES
Power
4xx-01x models
4xx-04x models
Supply Voltage
10 to 30 Vdc
PoE Device 48 Vdc
Consumption
0.7 to 0.2 A
13 W max.
Communication Interfaces
Main
- RS232
- RS485/422 full-duplex
2400 to 115200 bit/s
2400 to 115200 bit/s
Auxiliary - RS232
2400 to 115200 bit/s
ID-NET™
Up to 1Mbaud
Ethernet
10/100 Mbit/s
(supports application protocols: TCP/IP, EtherNet/IP, Profinet IO, Modbus TCP)
Inputs
Input 1(External Trigger) and Input 2
Opto-coupled and polarity insensitive; see note for PoE models
Max. Voltage
30 Vdc
Max. Input Current
10 mA
Outputs *
Output 1, 2 and 3
NPN or PNP short circuit protected; see note for PoE models
Vout (Iload = 0 mA) Max.
30 Vdc
Vout (Iload = 100 mA) Max.
3 Vdc
Iload Max
100 mA
OPTICAL FEATURES
Image Sensor
CMOS sensor with Global Shutter
Image Format
SXGA (1280x1024) pixels
Frame Rate
60 frames/sec.
Pitch
 35°
Tilt
0° - 360°
LED Safety
to EN 62471
Laser Safety (pointers)
IEC60825-1 2007
Lens
4x1-0xx models
4x2-0xx models
Focal Length
6 mm
9 mm
Focus Control
via adjusting screw
via software
Lighting System
Internal Illuminator
Aiming System
Laser Pointers
ENVIRONMENTAL FEATURES
Operating Temperature
0 to 50 C (32 to 122 °F) **
Storage Temperature
-20 to 70 C (-4 to 158 °F)
Max. Humidity
90% non condensing
Vibration Resistance
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
EN 60068-2-6
2 g @ 70 to 200 Hz; 2 hours on each axis
Bump Resistance
30g; 6 ms;
EN 60068-2-29
5000 shocks on each axis
Shock Resistance
30g; 11 ms;
EN 60068-2-27
3 shocks on each axis
Protection Class
EN 60529
IP65/IP67 ***
PHYSICAL FEATURES
Connector position 0°
Connector position 90°
Dimensions
95 x 54 x 43 mm (3.7 x 2.1 x 1.7 in.)
75 x 54 x 62 mm (3.0 x 2.1 x 2.4 in.)
Weight
about 238 g. (8.4 oz.)
Material
Aluminium
* when connected to the CBX connection boxes the electrical features for Output 1 and 2 become the following:
V
CE
= 30 Vdc max.; I
CE
= 40 mA continuous max.; 130 mA pulsed max.; V
CE saturation
= 1 Vdc max. @ 10 mA;
P
D
= 90 mW Max. @ 50 °C ambient temp.
** high ambient temperature applications should use metal mounting bracket for heat dissipation
*** when correctly connected to IP67 cables with seals.
