Datalogic Matrix 300 User Manual

CBX ELECTRICAL CONNECTIONS
63
4
Figure 51 - NPN Input 2 Using External Power
INPUT 3 CONNECTIONS (CBX500 Only)
Figure 52 - Input 3 Using External Power
CAUTION: Do not connect to I3A or I34B signals, they are reserved.
RESERVED
Pulled up to External
Input Device Power
Input
Signal
Input Device
