TYPICAL LAYOUTS
79
5
When using a Local Area Network (LAN), one or more Matrix 300s can be connected to the
network by using CAB-ETH-M0x cables:
Figure 72 - Ethernet Network Layout
Figure 73 - POE Ethernet Network Layout
CBX
Matrix 300™
Host
NETWORK
CAB-ETH-M0x
1
2
3
 Ethernet Interface
 Auxiliary Serial Interface (Local Echo) (RS232)
 External Trigger (for One Shot or Phase Mode)
Power
Matrix 300™
Host
PoE Switch
CAB-ETH-M0x
Ethernet Interface
