Datalogic QuickScan QD24 series User Manual

1D Symbologies Enter/Exit Programming Mode
Product Reference Guide 161
GS1 DataBar™ Expanded Set Length 1
This feature specifies one of the bar code lengths for GS1 DataBar™ Expanded Length Control
on page 160. Length 1 is the minimum label length if in Variable Length on page 243 Mode, or
the first fixed length if in Fixed Length on page 243 Mode. Length includes the bar code’s data
c
haracters only. The length can be set from 1 to 74 characters.
Table 17 provides some examples for setting Length 1. See page 243 for detailed instructions
on setting this feature.
Table 17. GS1 DataBar™ Expanded Length 1 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
01 Character 07 Characters 52 Characters 74 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT GS1 DataBar™ EXPANDED LENGTH 1SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘1’ ‘0’ and ‘7’ ‘5’ and ‘2’ ‘7’ AND ‘4’
5 Scan ENTER/EXIT PROGRAMMING MODE
$CXBL1
Select GS1 DataBar™ Expanded Set Length 1 Setting
Make a mistake? Scan the CANCEL bar code to abort and
not save the entry string. You can then start again at the
beginning.
~
CANCEL
DEFAULT
01 = Length 1 is 1 Character
