Enter/Exit Programming Mode Code 93
168 QuickScan™ I QD24XX/QBT24XX/QM24XX
Code 93 Set Length 2
This feature specifies one of the bar code lengths for Code 93 Length Control on page 166.
Length 2 is the maximum label length if in Variable Length on page 243 Mode, or the second
fixed length if in Fixed Length on page 243 Mode. Length includes the bar code’s check, data,
and full-ASCII shift characters. The length does not include start/stop characters. The length
c
an be
set from 1 to 50 characters. A setting of 0 specifies to ignore this length (only one fixed
length).
Table 20 provides examples for setting Length 2. See page 243 for detailed instructions on set-
ting this feature.
Table 20. CODE 93 Length 2 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
00 (Ignore This
Length)
07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODE 93 LENGTH 2 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
$CC9L2
Select Code 93 Length 2 Setting
Make a mistake? Scan the CANCEL bar code to abort and not save
the entry string. You can then start again at the beginning.
~
CANCEL
DEFAULT
50 = Length 2 is 50 Characters
