Datalogic QuickScan QD24 series - Source Radio Address Delimiter Character; Link Timeout

Enter/Exit Programming Mode RF Address Stamping
222 QuickScan™ I QD24XX/QBT24XX/QM24XX
Source Radio Address Delimiter Character
This option specifies the delimiter character to be placed between the label data and radio
address when address stamping is enabled.
$CBTAD
Set Source Radio Address Delimiter Character
To configure this feature, scan the ENTER/EXIT PROGRAM-
MING MODE bar code above, then the bar code at left fol-
lowed by the digits from the Alphanumeric characters in
Appendix D Keypad representing your desired char-
acter(s). End by scanning the ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to abort and
not save the entry string. You can then start again at the
beginning.
~
CANCEL
DEFAULT
00 = No Delimiter Character
This feature only applies if "Source Radio Address Transmission" on
page 221 is enabled.
Link Timeout
This feature specifies the wait time in one-second ticks for response from the remote. The
selectable timeout range is 01 to 40 (01-0x28) seconds in one second increments.
See page 236 for more information on setting this feature.
$CBTLT
Set Link Timeout
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code at
left followed by the digits from the Alphanumeric ch
ar-
acters in
Appendix D Keypad representing your
desired character(s). End by scanning the ENTER/EX
IT
bar code again.
Make a mistake? Scan the CANCEL bar code to abort and
not save t
he entry string. You can then start again at the
beginning.
~
CANCEL
DEFAULT
02 Link Timeout value is 2 seconds
