Enter/Exit Programming Mode MSI
172 QuickScan™ I QD24XX/QBT24XX/QM24XX
MSI Set Length 1
This feature specifies one of the bar code lengths for MSI Length Control on page 171. Length 1
is the minimum label length if in Variable Length on page 243 Mode, or the first fixed length if
in Fixed Length on page 243 Mode. Length includes the bar code’s data
characters only. The
length can be set from 01 to 50 characters.
Table 21 provides some examples for setting Length 1. See page 243 for detailed instructions
on setting this feature.
Table 21. MSI Length 1 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
01 Characters 07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT MSI LENGTH 1 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘1’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select MSI Set Length 1 Setting
Make a mistake? Scan the CANCEL bar code to abort and not save
the entry string. You can then start again at the beginning.
CANCEL
DEFAULT
01 = Length 1 is 1 Character
To Next Page
