Error Codes
Product Reference Guide
273
Table 49
Programming Mode
- The following indications ONLY occur when the reader is in Programming Mode.
Label Program-
ming Mode Entry
A valid programming label has
been sca
nned.
LED blinks continuously
Reader sounds four low fre-
quency beeps.
Label Program-
ming Mode Rejec-
tion of Label
A label has been rejected. N/A
Reader sounds three times at
l
owest
frequency & current vol-
ume.
Label Program-
ming Mode
Accept
ance of
Partial Label
In cases where multiple labels
mu
st be scanned to program one
feature, this indication acknowl-
edges each portion as it is suc-
cessfully scanned.
N/A
Reader sounds one short beep at
highest
frequency & current vol-
ume.
Label Program-
ming Mode
Ac
cept
ance of
Programming
Configuration option(s) have been
succes
s
fully programmed via
labels and the reader has exited
Programming Mode.
N/A
Reader sounds one high fre-
quency beep and 4 low frequency
beeps foll
ow
ed by reset beeps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has been scanned. N/A
Reader sounds two times at low
frequency
and current volume.
. Programming Mode Indications
Error Codes
Upon startup, if the reader sounds a long tone, this means the reader has not passed its auto-
matic Selftest and has entered FRU (Field Replaceable Unit) isolation mode. If the reader is reset,
the sequence will be
repeated. The following table describes the LED flashes/beep codes asso-
ciated with an error found.
NUMBER OF
LED FLASHES/
BEEPS
ERROR :
All Models:
QD24XX QBT24XX, GM44XX
CORRECTIVE ACTION
1 Configuration
Contact Helpdesk for assis-
tance
2 Interface PCB
6 Digital PCB
12 Imager
