264 QuickScan™ I QD24XX/QBT24XX/QM24XX
BT-Only Features
BT Pin Code
This option specifies the 4-character or 16-character pin code to be used for authentication of
the BT link. To set the pin code:
1. Scan the EN
TER/EXIT PROGRAMMING MODE bar code to enter Programming Mode, then
enable "BT Security Mode" on pa
ge 223.
2. Specify the desired pin code
length (4 or 16) by scanning the appropriate bar code in
"Select PIN Code Length" on page 22
4.
3. Determine the desired characters. For example, D254 or
STOR12345678135M
4. Convert the characters to hexadecimal using the ASCII Chart on the inside back cover of
this manual.
5. Go to page 224 and Scan the bar code: SET 4 CHAR PIN CODE
or SET 16-CHAR
PIN CODE.
6. Scan the appropriate alphanumeric characters from the keypad in Appendix D, Keypad,
representing the hexadecimal entries determined in the steps above. You will hear a two-
beep in
dication after the last character.
If you make a mistake before the last character, scan the CANCEL bar code to abort and not
save the entry string. You can then start again at the beginning.
7. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Programming Mode.
Changing the pin code setting will unlink the devices. If the Automatic Configuration Update
is set to the default enabled setting, the devices must only be relinked. If the Automatic Con-
figuration Update is set to the disabled setting,
the Pin Code setting must also be updated in
the Base Station using Aladdin. After the Base Station has been updated, the devices must be
relinked.
Figure 13. BT Pin Code Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
D254 STOR12345678135M
2
Convert the characters to
hexadecimal
44 32 35 34 53 54 4F 52 31 32 33 34 35 36 37 38 31 33 35 4D
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SET BT PIN CODE
5
Scan 8 or 32 Alphanumeric
Character
s Fr
om
Appendix D, Keypad
44323534 53544F5231323334353637383133354D
6 Scan ENTER/EXIT PROGRAMMING MODE
