6100 Counter
No. Setting Min. setting Max. setting Factory
setting
6101 Counter* Running, hours 0 32000 0
6103 Counter* GB operations 0 32000 0
6104 Counter* MB operations 0 32000 0
6105 Counter* Reset counter kWh OFF ON OFF
6110 Service timer 1
No. Setting Min.
setting
Second
setting
Max.
setting
Factory
setting
6111 Service timer 1 Type OFF Counting
down
Counting up OFF
6112 Service timer 1* Set point hours 1 32000 150
6113 Service timer 1* Set point days 1 1000 365
6114 Service timer 1 Fail class See description of fail classes
6115 Service timer 1 Output A Relay 0 Relay 5 Relay 0
6116 Service timer 1* Reset OFF ON OFF
6120 Service timer 2
No. Setting Min.
setting
Second
setting
Max.
setting
Factory
setting
6121 Service timer 2 Type OFF Counting
down
Counting up OFF
6122 Service timer 2* Set point hours 1 32000 150
6123 Service timer 2* Set point days 1 1000 365
6124 Service timer 2 Fail class See description of fail classes
6125 Service timer 2 Output A Relay 0 Relay 5 Relay 0
6126 Service timer 2* Reset OFF ON OFF
6130 Alarm horn
No. Setting Min. setting Max. setting Factory
setting
6131 Alarm horn* Timer 0.0 s 990.0 s 20.0 s
According to factory setting, the horn output will activate for 20 seconds when an alarm appears.
If the timer setting is adjusted to 0, the horn relay will be activated continuously, until the reset
alarm horn push-button is activated or the alarm is acknowledged.
6160 Run status
No. Setting Min. setting Max. setting Factory
setting
6161 Run status Timer 0.0 s 60.0 s 5.0 s
6162 Run status Relay output A R0 (none) R26 (relay 26) R0 (none)
6163 Run status Relay output B R0 (none) R26 (relay 26) R0 (none)
6164 Run status Enable OFF ON OFF
The running status detection has two purposes:
1. When the time delay period expires, all the alarms which have Enable selected to “Not
run status” will be activated.
The date and time can easily be synchronised with the laptop using the utility
software or changed manually via display.
