GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 108 of 123
6030 Nominal settings 4 (split ph)
No. Setting Min. setting Max. setting Factory
setting
6031 Nominal settings 4 Frequency 48.0 Hz 62.0 Hz 50.0 Hz
6032 Nominal settings 4 Generator power 4 kW 20000 kW 480 kW
6033 Nominal settings 4 Generator current 0 A 9000 A 787 A
6034 Nominal settings 4 Generator volt. 50 V 25000 V 400 V
6035 Nominal settings 4 Nom. RPM 4 0 RPM 4000 RPM 1500 RPM
6040 Transformer generator
No. Setting Min. setting Max. setting Factory
setting
6041 Transformer gen. Primary 50 V 25000 V 440 V
6042 Transformer gen. Secondary 50 V 480 V 440 V
6043 Transformer gen. Current prim. 5 A 9000 A 1000 A
6045 Transformer gen. Current sec. 1 A 5 A 5 A
6050 Transformer mains
No. Setting Min. setting Max. setting Factory
setting
6051 Transformer mains Primary 50 V 25000 V 440 V
6052 Transformer mains Secondary 50 V 480 V 440 V
6070 Genset mode
No. Setting Min. setting Max. setting Factory
setting
6071 Genset mode Set point Island Load takeover Island
6080 Language
No. Setting Factory setting
6081 Language English Master Master
6082 Language Selectable* No. 1
6083 Language Selectable* No. 2
6084 Language Selectable* No. 3
6085 Language Selectable No. 4 Customer translation
6086 Language Selectable No. 5 Customer translation
6087 Language Selectable No. 6 Customer translation
6088 Language Selectable No. 7 Customer translation
6089 Language Selectable No. 8 Customer translation
6090 Language Selectable No. 9 Customer translation
6091 Language Selectable No. 10 Customer translation
6092 Language Selectable No. 11 Customer translation
*See chapter regarding language selection.
If no voltage transformer is used, the setting 440/440 V can be maintained.
Each nominal setting can be selected by parameter 6006, M-Logic or by external
communication.
Transformer settings are ph-ph values, also when nominal settings 3 (1ph) is
selected.
The voltage set in nominal settings 4 is phase (L1) to phase (L2) values.
