GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 107 of 123
Alarm/limit function of relays
Alarm relay function: When an alarm activates the relay, it is activated as long as the
alarm is present and unacknowledged. If the off delay is set dif-
ferent from 0.0 s, a short reset of the relay will take place when
a new alarm appears.
Limit function: When an input activates the relay, no alarm message is dis-
played. After the condition activating this relay has returned to
normal, the relay will deactivate when the off delay has expired.
6000 Nominal settings 1
No. Setting Min. setting Max. setting Factory
setting
6001 Nominal settings 1 Frequency 48.0 Hz 62.0 Hz 50.0 Hz
6002 Nominal settings 1 Generator power 4 kW 20000 kW 480 kW
6003 Nominal settings 1 Generator current 0 A 9000 A 787 A
6004 Nominal settings 1 Generator volt. 50 V 25000 V 400 V
6005 Nominal settings 1 Nom. RPM 1 0 RPM 4000 RPM 1500 RPM
6006 Nominal settings Set
6010 Nominal settings 2
No. Setting Min. setting Max. setting Factory
setting
6011 Nominal settings 2 Frequency 48.0 Hz 62.0 Hz 50.0 Hz
6012 Nominal settings 2 Generator power 4 kW 20000 kW 480 kW
6013 Nominal settings 2 Generator current 0 A 9000 A 787 A
6014 Nominal settings 2 Generator volt. 50 V 25000 V 400 V
6015 Nominal settings 2 Nom. RPM 2 0 RPM 4000 RPM 1500 RPM
6020 Nominal settings 3 (1 ph)
No. Setting Min. setting Max. setting Factory
setting
6021 Nominal settings 3 Frequency 48.0 Hz 62.0 Hz 50.0 Hz
6022 Nominal settings 3 Generator power 4 kW 20000 kW 480 kW
6023 Nominal settings 3 Generator current 0 A 9000 A 787 A
6024 Nominal settings 3 Generator volt. 50 V 25000 V 230 V
6025 Nominal settings 3 Nom. RPM 3 0 RPM 4000 RPM 1500 RPM
The voltage set in nominal settings 1 and 2 is phase-to-phase values.
Which set of nominal settings is used can be chosen in parameter 6006.
Relays used in M-Logic strings must be set to limit function to work correctly.
