GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 120 of 123
10460-10620 Fuel level config. sensor
No. Setting Min. setting Max. setting Factory
setting
10460 Fuel level type Type 1 3 1
10470 VDO 1 Fuel level Input 1 0 ohm 180 ohm 0 ohm
10480 VDO 1 Fuel level Output 1 0 % 150 % 40 %
10490 VDO 1 Fuel level Input 2 0 ohm 180 ohm 40 ohm
10500 VDO 1 Fuel level Output 2 0 % 150 % 50 %
10510 VDO 1 Fuel level Input 3 0 ohm 180 ohm 50 ohm
10520 VDO 1 Fuel level Output 3 0 % 150 % 60 %
10530 VDO 1 Fuel level Input 4 0 ohm 180 ohm 60 ohm
10540 VDO 1 Fuel level Output 4 0 % 150 % 80 %
10550 VDO 1 Fuel level Input 5 0 ohm 180 ohm 70 ohm
10560 VDO 1 Fuel level Output 5 0 % 150 % 100 %
10570 VDO 1 Fuel level Input 6 0 ohm 180 ohm 80 ohm
10580 VDO 1 Fuel level Output 6 0 % 150 % 110 %
10590 VDO 1 Fuel level Input 7 0 ohm 180 ohm 90 ohm
10600 VDO 1 Fuel level Output 7 0 % 150 % 90 %
10610 VDO 1 Fuel level Input 8 0 ohm 180 ohm 100 ohm
10620 VDO 1 Fuel level Output 8 0 % 150 % 120 %
10630-10790 Oil pressure config. sensor
No. Setting Min. setting Max. setting Factory
setting
10630 Oil pressure type Type 1 4 1
10640 VDO 2 Oil pressure Input 1 0 ohm 180 ohm 30 ohm
10650 VDO 2 Oil pressure Output 1 0.0 bar 15.0 bar 4.0 bar
10660 VDO 2 Oil pressure Input 2 0 ohm 180 ohm 60 ohm
10670 VDO 2 Oil pressure Output 2 0.0 bar 15.0 bar 5.0 bar
10680 VDO 2 Oil pressure Input 3 0 ohm 180 ohm 90 ohm
10690 VDO 2 Oil pressure Output 3 0.0 bar 15.0 bar 6.0 bar
10700 VDO 2 Oil pressure Input 4 0 ohm 180 ohm 120 ohm
10710 VDO 2 Oil pressure Output 4 0.0 bar 15.0 bar 8.0 bar
10720 VDO 2 Oil pressure Input 5 0 ohm 180 ohm 150 ohm
10730 VDO 2 Oil pressure Output 5 0.0 bar 15.0 bar 10.0 bar
10740 VDO 2 Oil pressure Input 6 0 ohm 180 ohm 180 ohm
10750 VDO 2 Oil pressure Output 6 0.0 bar 15.0 bar 11.0 bar
10760 VDO 2 Oil pressure Input 7 0 ohm 180 ohm 210 ohm
10770 VDO 2 Oil pressure Output 7 0.0 bar 15.0 bar 11.5 bar
10780 VDO 2 Oil pressure Input 8 0 ohm 180 ohm 240 ohm
10790 VDO 2 Oil pressure Output 8 0.0 bar 15.0 bar 15.0 bar
HW 1.05 and SW 2.x.x have max. 2500 Ohm of all VDO sensors.
HW 1.05 and SW 2.x.x have max. 2500 Ohm of all VDO sensors.
