GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 29 of 123
Active binary input voltage: Dry contact inputs (see note)
3
V DC supply, with cable supervision
Relay outputs: Impedance: 240  ~ 16 mA
Relays 21-23: 30
V DC/AC 2 A
(UL/cUL Listed: 1 A Resistive)
Relays 45,47: 250
V AC/30 V DC 2 A
(UL/cUL Listed: 30 V DC/AC 2 A Resistive)
Relays 24,26: 30
V DC/AC 8 A
(UL/cUL Listed: 6 A Resistive)
1 status/config.
Relay 3-4: 24
V DC 1 A Resistive
Response times:
(Delay set to min.) Generator:
Reverse power < 400 ms
Power/overload < 400 ms
Over-current < 400 ms
Over-/under-voltage < 400 ms
Over-/under-frequency < 400 ms
Fast over-current < 300 ms
Mounting: Panel-mounted
(UL/cUL Listed: For use on a flat surface of a type 1 enclosure.
Main disconnect must be provided by installer)
Size: 160 × 220 mm (6.30” × 8.66”)
Climate: 97 % RH to IEC 60068-2-30, test Db
-20(-40) °C to IEC 60068-2-1
+70 °C to IEC 60068-2-2
Display: 128 × 64 pixel backlight STN
3 line views can max. show a value of 9999
Safety: To EN 61010-1, UL508 and CSA22.2 No. 14-05
Installation category (over-voltage category) III, 300 V, pollution
degree 2
Protection: Front: IP52/NEMA type 1
(IP65/NEMA type 1 with gasket, option L)
Terminals: IP20/NEMA type 1
To IEC/EN 60529
EMC/CE: To EN 61000-6-1/2/3/4
IEC 60255-26
Material: All plastic materials are self-extinguishing acc. to UL94 (V1)
Plug connections: AC voltage/current inputs: 3.5 mm
2
(13 AWG) multi-stranded
Other: 1.5 mm
2
(16 AWG) multi-stranded
(UL/cUL Listed: Wire size: AWG 30-12. Use min. 60/75 °C
copper conductors only)
