GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 30 of 123
Tightening torque: All inputs: 0.5 Nm (5-7 lb-in)
PC connection: RS-232 converter box (option J5)
or USB interface cable (option J9) for service use
Weight: 0.9 kg (1.9 lbs)
Installation: UL/cUL Listed: To be installed in accordance with the NEC (US)
or the CEC (Canada)
Approval: CE
UL/cUL Listed to UL508 and CSA C. 22.2 no. 14-05
UL/cUL Recognized to UL2200
Additional operator panel AOP-2
Operating temperature: -20 to 70 ˚C (-4 to 158 ˚F)
(UL/cUL Listed: Max. 60 ˚C ambient)
Storage temperature: -40 to 70 ˚C (-40 to158 ˚F)
Aux supply: 18 to 36
V DC by external DC/DC converter 12DCR24/5
(UL/cUL Listed: 12DCR24/5 supplied from controlled Class 2
source)
Wiring: Size: AWG 30-12
Use min. 60/75 ˚C copper conductors only
Tightening torque: 0.5 Nm (4.4 lb-in)
Mounting: Panel mounted
(UL/cUL Listed: For use on a flat surface of type 1 enclosure
Installation: UL/cUL Listed: To be installed in acc. with the NEC (US) or the
CEC (Canada)
Approval: CE
UL Listed to UL508 and CSA C22.2 No. 142-M1987
UL Recognized to UL2200
