V0505, 2.4
In ‘product drawing’ or ‘product edit’ of a 2D product you can program up to a maximal of 25
bendings per product (graphical programming).
These functions will be explained in the sections as indicated in the abovementioned overview.
Function keys:
insert /
delete
Delete an angle/line or insert an angle, depending on the
drawing cursor position (section 2.2).
precision To define selected line segment, with round cursor, for
high precision or if it is to be a "closing" dimension (sec-
tion 2.3).
bumping Bumping: when the cursor is on an angle you can create
an angle with a big radius (section 2.4).
change
data
To page with product data.
assign-
ments
To select assignments for bending sequence computations
(section 2.5).
bend
sequence
Program bend sequence (section 2.6).
