V0505, 7.8
uses the postprocess command to calculate a CNC program from a drawing with bendse-
quence, the control will allways take bend-allowance into account.
When a bend-allowance table is present and the cursor is on the parameter ‘active bend allow-
ance table’ then an extra function key is available: ‘edit table’. With this softkey the table can
be modified to meet user requirements. The table appears in a new window, with its own set of
function keys.
7.f
Each line contains a table entry, with several parameters. In this screen, the following function
keys are available:
Use the arrow keys to scroll to the field you wish to change. Then type the new value and press
Funtion keys:
new entry. Enter a new line in the table.
delete entry. Delete the current line.
save table. The table as it is shown on the screen is saved to memory.
