Delem
V0505, 7.9
ENTER. It is not possible to create a table through this menu. Only when a table has been
loaded into the control is it possible to edit its contents.
For more information about bend-allowance tables, we refer to the Delem manual of the bend-
allowance table.
Bottoming Force Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BF =
The pressure needed for an airbend multiplied by this factor in order to obtain the coin-
ing pressure.
Flattening offset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .OF =
The calculated depth position for the Y-axis beam in case of flattening your product
depends on the programmed flatten height of your special tool and the sheet thickness
(x2) and the here programmed offset to realise a flattened product as you require.
Z-distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ZD =
When automatic Z-axes are installed, the distance of the fingers on the backgauge are
automatically calculated with respect to the end of the plate.
7.g
