Replacing the optical-drive eject-button board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Align and place the optical-drive eject-button board, along with the cable on the chassis.
2. Replace the two screws (#6-32x6) that secure the optical-drive eject-button board to the chassis.
3. Secure the optical-drive eject-button board cable to the chassis using the securing clips.
4. Connect the optical-drive eject-button board cable to the I/O board.
Post-requisites
1. Replace the
front bezel.
2. Replace the handle bars.
3. Replace the left and right side-panels. See “
Replacing the side panels”.
4. Replace the stability foot.
101
