Replacing the front-bezel heat-sensor cable
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Route the front-bezel heat-sensor cable through the bracket.
2. Align the tab on the front-bezel heat-sensor cable on the chassis.
3. Push the release tab on the front-bezel heat-sensor cable and press it into place.
Post-requisites
1. Replace the
PCI fan.
2. Replace the left and right side-panels. See “Replacing the side panels”.
3. Replace the stability foot.
75
