Removing the memory modules
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1. Remove the stability foot.
2. Remove the left and right side-panels. See “
Removing the side panels”.
Procedure
1. Lay the chassis on the right side.
2. Locate the memory modules on the system board. For more information on the memory modules see “system-board components”.
3. Push the securing clip away from the memory module.
4. Remove the memory module from the memory-module slot.
NOTE: Repeat step 2 to step 4 to remove any other memory modules installed in your computer.
a. securing clip
b. memory-module slot
c. memory module
47
