Replacing the graphics card
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Align the graphics card with the PCI-Express card connector on the system board.
2. Place the card in the connector and press down firmly. Ensure that the card is firmly seated.
3. Replace the two screws (#6-32x6) that secure the graphics card to the chassis.
4. Connect the power cables to the graphics card.
NOTE: The location of the power supply connector (PCIE1, PCIE2 and PCIE3) varies depending on the video card installed.
5. From outside the chassis, push the screw covers inside to cover the screws that secure the graphics card to the chassis.
6. Connect the power cables to the graphics card.
Post-requisites
1. Replace the left and right side-panels. See “
Replacing the side panels”.
2. Replace the stability foot.
51
