Replacing the drive-bay heat sensor cable
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Route the drive-bay heat-sensor cable through the slot on the chassis.
2. Align the tab on the drive-bay heat-sensor cable on the chassis.
3. Push the release tab on the drive-bay heat-sensor cable and press it into place.
4. Lay the chassis on the left side.
5. Connect the drive-bay heat-sensor cable to the system board. See “
system-board components.
Post-requisites
1. Replace the left and right side-panels. See “Replacing the side panels”.
2. Replace the
stability foot.
