Replacing the processor
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
CAUTION: If either the processor or the heat sink is replaced, use the thermal grease provided in the kit to ensure that
thermal conductivity is achieved.
NOTE: A new processor ships with a thermal pad in the package. In some cases, the processor may ship with the thermal pad
attached to it.
Topics:
• Procedure
• Post-requisites
Procedure
1. Slide the processor cover into the processor slot.
2. Press the left-release lever and right-release lever on the processor cover to secure the tab.
3. Place the processor shield.
4. In the order as indicated on the processor shield (1,2,3), tighten the captive screws that secure the processor shield to the system
board.
82
